| Power (kVA) | 2 kVA |
|---|---|
| Gun Type | Portable Spot Welding |
| Electrode Force | 120 daN, 38 daN, 50 daN, 70 daN |
| Secondary Voltage (V) | 2,3 V |
- Light and proved spot gun for car body repair.
- Synchronous built-in electronic timer with SCR from 2 to 65 cycles.
- Compensation circuit starts the timer only when there is a proper passage of current, which enables to perform on oxidised sheets, on surfaces with paint residues or on black sheets.
- Force adjustment with scale in daN.
- Additional arm couplings to provide larger opening between arms.
- All transformer are coated with F class insulation material that does not dry out and become brittle. Test are made using 4000 volts.
- Supplied complete with 125 mm arms.
- Large choice of arms and electrodes.
